2006 HAAS VF-6D
Vertical Machining Centers
15,000 RPM Spindle
Thru Spindle Coolant
Air Blast
Programmable Coolant
Chip Auger
32 Bit Haas CNC Control
| X | 64" |
| Y | 32" |
| Z | 30" |
| Power | 20 hp |
| RPM | 15,000 RPM |
| # ATC | 24 |
| Taper | 40 |
| Table-W | 28" |
| Table-L | 64" |
| # Axis | 3 |
| Control | CNC (Haas) |
HAAS VF6D/40 VERTICAL MACHINING CENTER, NEW 2006, 15,000 RPM SPINDLE WITH THRU SPINDLE COOLANT
CATALOG SPECIFICATIONS:
64” x 28” Table
64” X-Axis Travel
32” Y-Axis Travel
30” Z-Axis Travel
20 HP Vector Drive
24 Side Mount ATC
40 Taper Spindle
15,000 RPM Spindle
Thru Spindle Coolant
Air Blast
Programmable Coolant
Chip Auger
32 Bit Haas CNC
MACHINE IS COMING OUT OF A PLASTICS COMPANY IN CALIFORNIA, LOOKS LIKE IT WAS MILLING PLASTIC.
15,000 RPM Spindle
Thru Spindle Coolant
Air Blast
Programmable Coolant
Chip Auger
32 Bit Haas CNC Control
| X | 64" |
| Y | 32" |
| Z | 30" |
| Power | 20 hp |
| RPM | 15,000 RPM |
| # ATC | 24 |
| Taper | 40 |
| Table-W | 28" |
| Table-L | 64" |
| # Axis | 3 |
| Control | CNC (Haas) |
HAAS VF6D/40 VERTICAL MACHINING CENTER, NEW 2006, 15,000 RPM SPINDLE WITH THRU SPINDLE COOLANT
CATALOG SPECIFICATIONS:
64” x 28” Table
64” X-Axis Travel
32” Y-Axis Travel
30” Z-Axis Travel
20 HP Vector Drive
24 Side Mount ATC
40 Taper Spindle
15,000 RPM Spindle
Thru Spindle Coolant
Air Blast
Programmable Coolant
Chip Auger
32 Bit Haas CNC
MACHINE IS COMING OUT OF A PLASTICS COMPANY IN CALIFORNIA, LOOKS LIKE IT WAS MILLING PLASTIC.
