2007 OKUMA GP-25T
Cylindrical Grinders Including Plain & Angle Head
Shoulder Gauge (Lateral Locating Gauge)
Coolant System
OSP U10G CNC Control
| Swing | 12.99" |
| Centers | 25.6" |
| Plain or Angle Head | Plain |
| Grinding Wheel Dia. | 24" |
| Dresser (Yes/No) | Yes |
| Control | CNC (OSP U10G) |
CATALOG SPECIFICATIONS:
12.99” Swing
25.6” Distance Bewteen Centers
110 Lbs. Max Workpiece Weight
24” Dia x 2.95” Wide Grinding Wheel
10HP Spindle Motor
8859 FPM Peripheral Wheel Speed
12.59” X-Axis Wheel Slide Travel
25.59” Z-Axis Travel
#4 MT Center HoleTaper in Work Spindle
#4 MT Center Taper in Tailstock
97.64” x 113” Floor Space Required
12,000 Approx Machine Weight
Equipped With:
Shoulder Gauge (Lateral Locating Gauge)
Coolant System
OSP U10G CNC Control
